After a lengthy period of inactivity, its always hard to jump back into game development. But I have done so, and with the help of a few tutorials to smooth my entry back in. I'll share them so you can check them out if you're interested.
This week saw progress in three key areas:
Smooth Camera System
Pause Feature
Room Warping
-
Smooth Camera System
Notice the weird vibration? That's because the camera hated "sub-pixel" movement.
Although it's hard to tell from gifs with a low frame rate, my old camera system wasn't working properly in my new gamemaker project. I'm not entirely sure why (because it works within my old project file), but I fixed it by moving code in my [Step] Event to the [End Step] Event.
The player character moves 1.3 pixels every frame (like Megaman), but the built-in camera for Gamemaker can only move in integers (or whole numbers without decimal points). This means the camera can't keep up with the player, causing the character to vibrate while they move.
I won't spend much time explaining this system because I haven't coded anything new, but I will share two examples of a smooth camera system -- which have a lot in common with my solution. PixelatedPope in particular spends a lengthy amount of time explaining everything, with visuals, in a way that is easy to understand for a non-coder.
My old pause functions were a bit messy, using different solutions for different things.
For the primary pause feature:
Display screenshot of game.
Deactivate all game objects (hiding them, hence why we took a screenshot).
For dialogue:
Make objects exit their [Step] event.
... This needed to be hand-placed into every single object I wanted to pause.
The latter solution actually results in a bug within my previous engine. If you press the Mel Talk button while on crumbling floor tiles, the tiles will break apart and kill the player mid dialogue -- because I forgot to tell that specific object to exit its code.
Funnily enough, PixelatedPope recently uploaded a video on the subject. In it, he outlines both cases and explains the possible problems they cause. As a result, I decided to use his design.
PixelatedPope's Approach:
Create a "pause manager" object that runs 100% of the code.
Assign a "CanPause" tag to every relevant object within the IDE.
In the pause manager: DE-activate all tagged objects in the [Draw GUI End] Event.
In the pause manager: RE-activate all tagged objects in the [Pre-Draw] Event.
For context: All objects process a sequence of events that run one after another. For instance: Create Event > Step Event > Step End Event > Draw Event > Draw GUI Event > etc... All of that happens between each frame of the game.
So we de-activate every object after it is drawn, skip the logic events, then re-activate before the draw events. As a result, we can prevent code from running but still draw the objects. My previous solutions are obsolete, as long as I don't put any "logic" code in the Draw Events.
I still need to see if this system can be easily plugged into other actions that pause the game, like dialogue and illustration displays. But it's an overall improvement, and it's good to get this done early so I'm not forced to refactor older code around it (and risk error like I did before). It's not really worth showing off, but it's part of the engine now.
I've also revamped my room transition system / warps / doorways / etc.
I assigned a target room and target X & Y coordinates, then moved those into a global variable (the entire game keeps track of these all the time). The exit objects load the new room and the player object is created at the target coordinates.
OLD VARIABLE DEFINITIONS
It worked great, but it was a lot of work to set up every time - especially if the target position is on a staircase (as I had to manually place the character inside each room and line them up with the stairs at the right angle to get the correct coordinates for each room transition).
So, I wanted to simplify this process, inspired by RPG Maker, Mario Maker, and ZeldaClassic. In my new idea, instead of manually writing down the coordinates for each room transition, I'd instead place an "entrance" object linked to the "exit" object in the previous room.
NEW VARIABLE DEFINITIONS (WIP)
Using a persistent "room transition" manager, I can have the [o_room_exit] object refer to a specific [o_room_entry] object, and simply move the player to that position once the room is warped to. Conveniently enough, PixelatedPope had a tutorial for the same exact thing, albeit a bit more streamlined than my design -- using far fewer variables.
These systems still need a little tinkering, but they're the bulk of what's needed for the basic building blocks of a simple game environment in terms of basic mechanics. We now have: movement mechanics, smooth camera control, pausing, and room transitions.
It may be worthwhile creating a simple game that only contains platforming, however, so that we can properly test to make sure the new collision mechanics and upgraded systems work without any issues.
You can view this content for free after you Log In or Sign Up.
Devlog - Ropes and Elevators
The latest game dev updates have taken quite a bit, but here we are.
Ropes
Rope Climbing is a feature previously exclusive to the GameBoy Castlevania titles that were an alternative to stairs. I featured it in the previous Beaumont Prototype, and now its back in the current version of the engine too.
The implementation is mostly the same, though slightly improved. There was a small issue in the old engine -- jumping from one rope to another will cause the player to land at a higher Y position than their jumping-off point on the previous rope. I've fixed it with a magic number, which I'm not particularly fond of. But it seems to work, maintaining the player's Y position.
If you're wondering what that giant diagonal line sticking out of Elayne's body is - its a line checking for collision with ropes, so the game knows if there's a rope to grab.Player can move, jump, and quickly slide down...
Moving Platforms
I've added moving platforms - elevators that can move horizontally and vertically, carrying players across distances, providing another means to move across the game world.
Classic CV rarely use moving platforms, but when it does, they mostly move horizontally. Thus, I did not need to implement vertical moving platforms, but I really wanted that feature, which is why this mechanic took so long to code. The old engine actually has moving platforms, but they were constantly breaking, so I never used it in prior demos...
Glass shape is important. You can either go tall or wide, we call them vertis and horis (vertical or horizontal)
Programming this feature was a constant challenge, with the player often falling through the platform or getting stuck inside of it. Neither are things you want to happen while platforming.
When colliding with blocks via gravity, I am simply detecting the player's future position and stopping movement before collision so the player doesn't land inside of [o_solid]. But there is a wrinkle with this approach when colliding with the [o_solid_moving].
Moving Platforms ALSO move, so I must account for the platform's future location too. This is to prevent players from landing inside of a platform as it moves up while players move down. It's a relatively small difference, but this is the first time I've had to account for that.
I'm still not sure if I'm totally happy with it, but it works.
Combining moving platforms with a slide to ignore obstacles seems interesting...
Room Editor Tools
Problem solving aside, this is a good opportunity to show off how my room editor tools work.
A lot of my level kit is comprised of individual objects. Instead of handling everything through variable drop-down menus, objects are designed to detect one another on Creation and use that info to run specific blocks of code.
For example:
Place Loot Object above Treasure Chest Object.
Save Loot Object ID to Treasure Chest during Create Event.
Destroy original Loot Object before players see anything.
Now the Chest will provide the Loot Object as a reward.
As a result, I can easily see how my level is supposed to work from a quick glance at the map. This was inspired by Mario Maker and online maps for retro games that show item locations.
In the case for moving platforms, there are only two objects:
Moving Platform, [o_solid_moving]
Moving Platform Point, [o_platform_point]
The Platform Points are two instances of a single object, and its identity as Point A or B is determined by the frame of its animation sequence when created. If image_index is 0, then it is A, otherwise it is B. I can simply change its current sprite / active frame in the room editor -- and everything will work as expected even if I drag the objects to different coordinates.
You can see this concept in action in this YT video by ItsHyomoto HERE.
Room Editor: Inspectors for Each Object
Duct Tape Solution
Despite the presumed success of my moving platform logic, players can still fall through the platform if their body is inside of [o_solid] due to a quick of my collision code turning the feet collision off under certain conditions.
To fix that, I've created collision lines below the player. If the player is falling, while inside of [o_solid], check for an instance of [o_solid_platform] below the player. If an legal instance is found, the player is then pushed out of the block. It is noticeable if you're paying attention, but I hope it won't be an issue.
The next goal on my agenda will probably be adding tiles that modify movement, like water & conveyor belts. I might let that wait until there are more "actor" objects, but we'll see.
You can view this content for free after you Log In or Sign Up.
Devlog - Automatic Stairs Creation
Following up on the latest feature in the previous blog post; the improved stairs system.
My prototype system for stairs was a relatively simple one - with only 2 main objects (the top & bottom entry points). Instead of treating stairs like a physical object, players would instead enter the "on stairs" state, only allowing them to move diagonally. That is how the original CV games did it, but can't work if we want players to land ON stairs after a jump. So we created a new object [o_stairs_mid] and placed one at each tile of the entire staircase.
The problem with this solution is that it requires I hand place every single step for every single staircase in every single room. It is extremely prone to user error, and if I wanted to move any of the staircases, I'd have to move EVERY single step. That's annoying.
So I've decided to automate the process, though this was a bit tricky.
My initial plan was to have [o_stairs_mid] duplicate on creation until it meets [o_stairs_top], but GameMaker wouldn't allow this because it could result in an infinite loop...
So I came up with another solution; involving measuring the desired length of each staircase to automatically create the amount of steps needed between both entry points. ---
Outline of Behavior
But this was still tricky... [o_stairs_bottom] needs to find the EXACT [o_stairs_top] I wanted. Using a collision_line to detect the top entry could still choose incorrect instances, such as:
Instances at the same X coordinate as my desired instance (like right next to it).
Instances above my desired Instance, but still along the collision line.
So here's what I'm ultimately doing: send out a collision line, save a list of every single entry the line touches, then filter out any instances that have a different direction (image_xscale), then loop through that list of entries, and select the closest instance.
Once I've found the closest instance, I measure the distance between the two entries in tiles, then [o_stairs_bottom] will create [o_stairs_mid] along the line until they meet [o_stairs_top]. Now, I only need to hand-place the entries and the engine will handle the rest on its own.
Automatic Stair Generation!
---
Get Equipped with the power to lie dormant for 8 years.
Oh, and I've added a slide ability.
This is a feature I've planned to include since the early prototype, but its inclusion was never essential, so I never spent time to include it. When the player starts sliding, they get a sudden burst of speed, and they decelerate over time.
I thought about making it identical to Mega Man's slide, but worried it would be too fast that too many people would prefer it over walking. That slide also would make it easier to die too...
I still need to create original art for it.
---
I hope everything works as intended. I have a nearly complete basic movement system, assuming I don't do extra stuff like wall jumps or back flips.
I'm noticing an issue with sprite warping (presumably due to sub pixel movement) and my old smooth camera system doesn't fix it (but it still works perfectly in my prototype even after it has been converted into the latest version of Gamemaker). So I might need to create a new camera system or find out why it's happening.
You can view this content for free after you Log In or Sign Up.
Devlog - Improved Stairs & Collision
I have done more work on the Beaumontvania Engine.
But first, to reiterate a previous point:
In Castlevania, players can jump through ceilings from underneath, but will be blocked from jumping into a block's side. I accomplished & discussed this in my last blog post.
While this behavior is perfectly fine, I did want to introduce some of the additional quirks seen in the Bloodstained: Curse of the Moon games (which also recreate classic CV). There are two features in particular that I wanted:
The ability to jump when there are blocks directly above you. In CV (and my engine), the player is unable to execute a jump if there is a block above their head when grounded.
The ability to jump through ceilings and land on top of them.
Although the player's jump is too low to naturally jump through ceilings, I want the engine to at least be capable of supporting this feature in the case of a double jump, for example.
However... There is an obstacle! The player's feet is constantly checking for collisions. If the player attempts to jump through a solid, the feet will detect [o_solid] and interrupt their jump - causing the player to immediately bounce back down.
I solved this by modifying the foot collision -- basically: if players are inside of a solid during a jump, then consider their character as NOT grounded, and do not interrupt their jump.
Behold! Unlimited Power! The ability to jump through ceilings.
---
This has caused bugs, however.
One issue is that players can fall through floors because portions of their body are technically inside of [o_solid] even when they should be grounded. I have fixed this (I hope).
Here's one such solution:
If players are jumping and within a solid... And their feet detects [o_solid] below, but the feet themselves are NOT inside of a solid, then treat the player as grounded. Otherwise, we can treat them as not grounded.
I hope they're fixed, anyway. But let me show you those bugs anyway, just for fun.
Bug. Player's knee is inside wall, so player's Feet Detection was never re-enabled.Bug. Player's back is inside wall, so Feet Detection was never re-enabled.Unrelated Bug. The body thought this area was a legal space to stand.
---
I have also implemented stairs (and much more efficiently than before). There might be one thing about the older code that is slightly better, but the newer code is faster, requires less lines of code, and requires less individual objects per staircase by default.
But I've also added a new feature - the ability to jump onto stairs.
This feature was not present in the original CV trilogy, but was seen various titles, such as CV: Bloodlines, Super Castlevania IV, Rondo of Blood, and even Bloodstained: Curse of the Moon.
This feature does make stairs a bit more complicated, and was the primary reason I never had it in the Prototype. Its inclusion also means that staircases now require additional objects... In fact, one additional object for every 16 pixels (or tile).
In the prototype, stairs were comprised of two tangible objects - a top & bottom entry point. The rest of the stairs did not exist; players were instead put into a unique state where they can only move diagonally until they exit via one of the entry points.
But to accommodate the ability to land ON stairs, every step needs an object to detect.
I hope there are no bugs present, but I would not be surprised if there were. I don't know if there's any real demand for it, but players can also lock their movement while holding A too. Player can Jump onto stairs, drop off stairs, and lock position.
I can use basic math to determine the correct coordinates for players to land.
If [o_stairs_mid] is drawn from its bottom-left corner (0, 0) and players run across the stairs in a perfect diagonal line, then coordinates for the top-right corner are (16, 16). If players land on the stairs on its 8th horizontal pixel, then their feet should also be on the 8th vertical pixel. But this is very tricky when dealing with gravity pulling players down in sub-pixels very quickly.
So: I find the difference between [o_player.x] and [o_stairs_mid.x] (origin: 0,0) to determine how far long the player is along the horizontal axis (let's say they're 12 pixels deep). I then take 12 and add it to the stairs vertical axis, ensuring a perfect 1:1 ratio.
So, when players enter the stairs while falling, I then FORCE them to those coordinates. This can sometimes result in an abrupt jittery animation though.
---
Oh, and players now have the ability to drop off stairs.
Although this feature was not in very many games, they were present in SC4 & RoB -- which are probably the two most iconic "classic-style" games in the franchise for many fans. That said, I was uncertain about its inclusion because:
It makes stairs less risky than they already were (due to Elayne's speed) since players can now instantly exit staircases on command.
Players may accidentally drop off stairs and die.
The Curse of the Moon games never included the ability to drop off of stairs despite allowing players to jump onto them. I can only assume the reason for this choice was because it was better for the game design & balance... So might it be a mistake for me to include it? I am also less inclined to give players methods to rush through or ignore tangible gameplay mechanics.
But it's good that my engine is, at the very least, capable of supporting these features now.
You can view this content for free after you Log In or Sign Up.
Devlog - New Elaynevania Collision System
Surprise! A gamedev update? In the year of our brell, 2026?!
I have recently started to recreate my Beaumont-vania engine in the hopes of making a better version from scratch. So I thought I would share my recent developments - and more openly.
---
Screenshots from Bloodstained: Curse of the Moon 2, which uses a recreation of Castlevania's mechanics.
In the classic Castlevania games, players interact with the world in a rather unique way:
Players will ignore collision with blocks (or o_solid) above their heads, allowing their jump arc to continue without interruption. But when jumping into [o_solid] from its side, the players will instead be prevented from moving horizontally, blocked by the wall ahead of them.
These behaviors can also occur simultaneously: players may overlap ceiling tiles while also being blocked by walls at the same time. This can be a little tricky to replicate. If our method to detect collisions is a simple rectangle that covers the player's body using place_meeting, then players would likely hit their heads on the ceiling, like in most games.
So the solution used in my prototype is similar to Castlevania's (and many other NES games): using a set of collision_points instead, all placed across the player's body to detect [o_solid].
However, different player states (move, jump, etc.) all required using different collision points, forcing me to keep track of 6+ points across different blocks code just to detect [o_solid].
Old Code - Macros for Collision Points (very messy)
Each state used their own collision points, and the airborne states all had their own variations of repeated code, introducing several opportunities for inconsistency & bugs... My logic also suffered from a few "magic numbers" and even resulted in players getting stuck on blocks.
This collision system was a constant problem across the game's development.
---
However, I recently designed a new system in a fresh project; even using a rectangle with place_meeting to check for collisions despite my earlier statement.
This requires some clever problem solving - inspired by Programancer's method for TASQ.
Instead of checking for collisions with:
place_meeting(x, y, o_solid)
I am using:
place_meeting(x, y_offset, o_solid)
Instead of detecting collisions at the player's Y coordinate, we're checking a dynamic position that changes using a customlocal variable [y_offset]. This basically lets us trick the code into thinking the player is not PHYSICALLY inside of the block, allowing uninterrupted jump arcs.
So, when checking to see if players can move horizontally:
If the player is OUTSIDE of [o_solid], check for blocks AT the player's height.
If the player is INSIDE of [o_solid], check for blocks BELOW that [o_solid]'s bottom edge.
As a result, since [y_offset] is being lowered below the active ceiling, players can still bump into walls on the side, as those walls are ALSO below the active ceiling - achieving our goal of recreating Castlevania's environmental collision.
Although not accurate to the written code, this is basically what is happening.
---
I have also created a script for generic jump movement to use in all relevant airborne states, so that I can re-use it without having to write it more than once. If any changes are made to it, then it will be reflected in ALL of the player states that call this script automatically.
Moving forward, I plan to use this strategy more often -- creating "building blocks" of logic to re-use across multiple scripts & objects instead of hard-coding similar behavior every time.
Helper Script: Handles horizontal movement, for use during all airborne states (Jump, Fall, Jump Whip, etc.)
Player Jump State Script: Calls the Helper Script, but does not handle any horizontal movement itself.
My new logic is still work-in-progress, but has proven fairly successful so far. The new logic is cleaner and doesn't have many of the "wall clipping" problems my last system did. I found a notable bug in the Helper Script's second condition, but it otherwise works fine. Still, I do need to fix that, so the shown code does not reflect the final product. I want to make sure this behavior is perfect before adding any other player actions.
It may be worthwhile to create a game focused on platforming without complex mechanics, so that it would be much easier to test & receive patron feedback without other mechanics getting in the way.
---
This game development blog post is different from previous posts because it focuses solely on logic and code, which I imagine limits the overall entertainment value for most viewers -- but it is interesting, and an important part of the development process.
I'd also like to be less rigid with my devlogs by not requiring it to always highlight new art or features, so diversifying is nice. Whether that's showcasing a linear progression of the game engine, general game design concepts, or even experimenting with other game ideas...
